12.8V 18Ah LiFePO4 Battery Pack For UPS System Lead Acid Battery Replacement

원래 장소 중국
브랜드 이름 G-Tech power
인증 CE and ROHS
모델 번호 LEP12.8-18
최소 주문 수량 1000
가격 negotiable
포장 세부 사항
배달 시간 30 일
지불 조건 전신환, 웨스턴 유니온, L/C (신용장)
공급 능력 50,000PCS/DAY

Contact me for free samples and coupons.

왓츠앱:0086 18588475571

웨이 채팅: 0086 18588475571

스카이프: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
제품 상세 정보
공칭 전압 12.8V 전지 성능 18Ah
리듐-이온 타입 LiFePO4 에너지 230.4Wh
OEM 서비스 이용 가능합니다 싸이클 수명 >2000 사이클 @1C 100%DOD
BMS 4s20A
강조하다

18Ah Deep Cycle Lithium Ion Battery

,

18Ah LiFePO4 Battery Pack

,

Lead Acid 12.8 V Lithium Ion Battery

메시지를 남겨주세요
제품 설명
12.8V 18Ah Deep Cycle Safety Lithium-Ion Battery For UPS System Lead Acid Battery Replacement
G-TECH POWER Oriented with the Japan technology, the only one Chinese factory own the Japan technology, G-TECH company strongly focus on quality control. By being strictly, we prevent sub-standard products from appearing in the market or high scrap rates during production.

We offer a wide product range to our customers and prospects.
In the VRLA range this includes Security batteries, high-rate batteries for power supplies; Deep-cycle batteries for energy storage; OPzV & OPzS tube batteries, Lithium-Ion battery(LiFePo4 battery)...


WHY LITHIUM-ION?

MORE POWER: lighter than lead-acid and packs more power. Our batteries deliver higher power during cranking, and hold a higher voltage during discharge than a comparably sized lead acid battery. That means a hotter ignition, faster starts, and more watts for your accessories.



LIGHTER WEIGHT: Because the lithium powering G-TECH's Lithium batteries produce more pound-per-pound power than lead-acid, less materials are needed. The result is a lighter battery. In fact, some models are so light they float, making them ideal for racing and marine activities.



FASTER RECHARGING: g-tech's lithium-ion batteries accept charge current up to 5x faster than lead-acid batteries, and in many cases Lithium Pros’ batteries recharge in less than an hour.



LONGER BATTERY LIFE: G-TECH lithium-ion batteries provide over 5x the cycle life at 80% DOD (depth of discharge) compared to standard lead-acid batteries, and easily handles 2,000 cycles.



MORE EFFICIENT: G-TECH batteries are 96% efficient at converting input energy into stored energy versus approximately 75% for lead acid.



SAFE & ECO-FRIENDLY: G-TECH Lithium-ion batteries do not contain toxic materials (lead/acid), or emit harmful gases like standard lead-acid batteries. Also, our batteries use Lithium Iron Phosphate which is the safest form of lithium chemistry.





12.8V 6Ah lithium-ion battery

12.8V 18Ah LiFePO4 Battery Pack For UPS System Lead Acid Battery Replacement 0

MODEL:LEP12.8-6
12.8V 18Ah LiFePO4 Battery Pack For UPS System Lead Acid Battery Replacement 1
12.8V 18Ah LiFePO4 Battery Pack For UPS System Lead Acid Battery Replacement 2

Features:

Long Cycle Life: offers up to 20 times longer cyecle life and five times longer float/calendar life than lead acid battery,
helping to minimized the replancement cost and reduce the total cost of ownership.

Light weight: about 40% of the weight of a comparable lead acid battery . A " drop in" replacement of lead acid batteries.

High power: delivers twice power of lead acid battery, even high discharge rate, while maintaining high energy capacity.

Superior Safety: Lithium-ion phosphate chemistry eliminates the risk of explosion or combustion due to the high impact,
overcharging or short circuit situation.

wide temperature range: -20℃~60℃

increased flexibility: modular design enable deployment of up to four batteries in series and up to ten batteries in parallel.

Application:

Emergency Light
Security System
Illumination light
Fire alarms
Medical equipments
UPS system
lighting
Telecommunincation
Electric velhicles

Specification
Nominal Voltage
12.8
Nominal Capacity
12Ah (C5,25℃)
Energy
153.6Wh
Cycle Life
>2000 cycles @1C 100%DOD70A (5 sec)
Charge Voltage
14.6±0.2V
Charge Current
20A (max is 20A)
Charge Cut-off Voltage
14.8V±0.2V
Continuous Current
20A
Discharge Cut-off Voltage
10V
Dimensions (in./mm.)
181*77*168 mm
Weight (lbs./kg.)
2.8Kg
Plastic Cas
ABS
Terminal
M5
Protocol (optional)
NO
BMS
4S20A



Cycle life curve
